OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating

Product Categories
U-Safe Technology Co., Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating

Clear aperture : >95%

Thickness : 0.3-5.0mm

Model Number : BS

Brand Name : Non

Place of Origin : Guangdong, China

Coating type : IAD multilayer dielectric coating

Square size : 2mm*2mm-146mm*146mm

MOQ : 1000

Price : $1

Material : K9, BK7, B270, D263T Quartz glass

Round size : 3mm-110mm

Name : Optical Elements

Contact Now

K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating and MIL-STD-810F Environmental Testing
Product Overview
The beam splitter plays a crucial role in separating light source energy and changing light path direction in optical systems. Featuring a relatively simple structural design with minimal light absorption, our beam splitters ensure low loss after light splitting. Key characteristics include a flat all-dielectric coating splitting ratio, a wedge surface of 30 arc minutes on the back, and superior anti-reflection effects to eliminate ghosting and stray light. Ideal for microscopic imaging, machine vision, laser beam splitting, and 3D synthesis applications.
OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating
Technical Specifications
Product Name Beam Splitter
Customized Support OEM, ODM
Place of Origin China
Model Number BS
Coating IAD multilayer dielectric coating
Anti-reflection Coating Working wavelength, R<0.5%
Beamsplitter Coating 200-1100nm
Material K9, BK7, B270, D263T Quartz glass
Round Size φ3mm-110mm
Square Size 2*2mm~146*146mm
Clear Aperture >95%
Surface Quality 40-20(S/D)
Optical Density (OD) OD2-OD4
Thickness 0.3-5.0mm
Environmental Testing MIL-STD-810F
OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating
Typical Applications
Application Size Spectral Wavelength Spectra Ratio
Optical communication LD pumps 2*2*0.3mm 850nm T:R=60:40
Lasers 3*4*0.31mm 532nm T:R=90:10
3D measurement 10*20*0.3mm 500-650nm T:R=50:50
Laser lamp 10*2*1.1mm 465nm T:R=50:50
Fiber optic face inspection 15*18*0.3mm 420-680nm T:R=50:50
Digital microscope 25*35*1.1mm 420-680nm T:R=60:40
Machine vision 84.5*62*1.1mm 420-680nm T:R=50:50
Coaxial light 102*142*1.1mm 420-680nm T:R=70:30
Spectrum Demonstration
OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating
Product Gallery
OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating
Production Process
OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating
Company Profile
OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating
U-safe Technology Co., Limited (hereinafter shorted as U-SAFE) is legally registered in Hong Kong, operating as a B2B trading company that builds business bridges between Chinese factories and overseas importers. We help you obtain the correct products and solutions safely, easier, and faster. Our office is strategically located in IC Park Shenzhen, China for closer coordination with manufacturing partners.
Contact & Support
OEM Optical Elements K9 BK7 Material Polarizing Beam Splitter with IAD Multilayer Dielectric Coating
Welcome Inquiry! Any questions? Please talk with our sales team - you will receive a reply within 24 hours at the latest!
Our Services
  1. R&D / OEM Support
  2. Production Process Follow-up
  3. Custom Packaging Solutions
  4. Pre-delivery Inspection
  5. Comprehensive Shipping Options: EXW, FOB, FCA, CNF, CIF, Door to Door by sea, air, express, or post
